Agent API

Last updated

A REST API for autonomous agents. Requests carry a bearer key; orders run on the production evaluation engine with simulated execution, against agent sessions that never touch funded capital or an on-chain payout.

Console

Every endpoint, with its real request shape and a response you can read. DEMO answers from a recorded example of what the endpoint returns, without leaving your browser; LIVE calls the API with a key you paste in. A key typed here stays in the tab — it is never stored, never logged, and never sent anywhere but this API.

POST/api/v1/agent/ordersscope: trade

Place an order against an agent session.

RESPONSE

Nothing sent yet. In DEMO the response is a recorded example of this endpoint's real shape — no request leaves your browser. Switch to LIVE to call the API with your own key.

  • 200The order was accepted and filled against the recorded price
  • 400The body is malformed, or clientOrderId is missing
  • 409The session is closed, or the key was reused with a different payload
  • 401The key is missing, unknown, revoked or expired
  • 403The key does not hold the scope this endpoint needs
  • 404No such agent account — or it is not yours. The two answers are identical on purpose
  • 429Rate limited. `Retry-After` says when to come back
CURL
curl -X POST "https://app.cats.fund/api/v1/agent/orders" \
  -H "Content-Type: application/json" \
  -d '{"accountId":"2894802230932904885589274625217197696331749616641014100986439600197828240999","symbol":"BTC","side":"long","intent":"open","size":"0.01","clientOrderId":"console-1788896751418"}'

The loop, running

What an agent actually does: read a price, decide, place an order, watch the fill. Replayed over 90 real recorded one-minute BTC candles — nothing leaves your browser.

DEMOAgent loop · BTC
$80,612.00▼ 0.02%
EMA 12EMA 26BollingerRSI 35
Equity
$25,000.00
Position
flat
Unrealised
+$0.00
Fills
0

Press Run agent. Every 420ms the loop reads the next candle and runs four steps:

  1. read the close, and the moving averages either side of it
  2. decide — a crossover is a signal, anything else is nothing
  3. call POST /api/v1/agent/orders
  4. settle — the fill, the position, the P&L

90 real recorded one-minute BTC candles. Nothing leaves your browser.

Connect a model

One MCP server. Claude, OpenAI and Gemini all speak the protocol natively, so the same 5 tools appear in every host from one URL — no adapter per provider, and nothing to keep in step when the API changes.

https://app.cats.fund/api/v1/mcp

  • 5 tools
  • 1 mutating, gated
  • 2025-11-25 protocol
import Anthropic from "@anthropic-ai/sdk";

const client = new Anthropic();

const response = await client.beta.messages.create({
  model: "claude-opus-5",
  max_tokens: 16000,
  betas: ["mcp-client-2025-11-20"],

  mcp_servers: [
    {
      type: "url",
      url: "https://app.cats.fund/api/v1/mcp",
      name: "cats_fund",
      authorization_token: process.env.CATS_API_KEY,
    },
  ],

  // The server definition alone is rejected — the toolset is what
  // enables the tools. Here it also denies the one tool that moves
  // money, so the agent can read the book all day and cannot trade.
  tools: [
    {
      type: "mcp_toolset",
      mcp_server_name: "cats_fund",
      configs: {
        "cats_place_orders": {enabled: false},
      },
    },
  ],

  messages: [
    {
      role: "user",
      content: "What is my open exposure, and how is P&L trending?",
    },
  ],
});

console.log(response.content);
Tools published
cats_place_orders, cats_get_orders, cats_get_positions, cats_get_equity, cats_get_account — derived from the endpoints above, so a tool cannot describe one that does not exist.
Mutating
Only cats_place_orders changes state, and it is published with readOnlyHint: false so a host can tell. Anthropic can disable it outright from the toolset config; OpenAI can leave it off the never-approve list so it prompts. Both are shown above.
Transport
Streamable HTTP, protocol 2025-11-25. One POST, one JSON answer — the server holds no session, so a key is all a call carries. The deprecated SSE transport is not offered, and Gemini would refuse it anyway.
Not exposed
Key issuance and revocation. Those are cookie-authenticated decisions a person makes — an agent holding a key cannot mint another.

Reference

The rest of the API, four ways in. Everything below is on the page at once without JavaScript — the tabs only shorten the scroll.

Production engine

The same fill logic, drawdown rails and recorded venue prices a person trades against. Not a sandbox reimplementation.

Simulated execution

No order reaches an external venue. Fills are computed against recorded prices and stored, exactly as an evaluation's are.

No funded capital

An agent session cannot acquire a certificate, enter an epoch, or produce a payout — those live in tables an agent id cannot appear in.

Authentication

Header
Authorization: Bearer <secret>
Scopes
trade to place orders, read for everything else.
Never both
Send a key or a session cookie. A request carrying both is refused rather than resolved by precedence.
Rate limits
Per key, not per address — moving between addresses gains nothing. Reads 600/min, orders 120/min. A 429 carries Retry-After.

Getting a key

Keys are requested and approved, never self-served. You generate the secret yourself, so we never hold it.

  1. Ask

    POST /api/v1/keys/request, signed in with your wallet.

  2. Wait for review

    An operator approves it. Nobody self-serves a key.

  3. Claim

    Generate 32 random bytes and send only their SHA-256. The secret never leaves your machine — so we cannot lose it, leak it, or show it to an operator, and a missing response is safe to retry with the same hash.

SECRET="ck_live_$(openssl rand -base64 32 | tr '+/' '-_' | tr -d '=')"
    HASH=$(printf '%s' "$SECRET" | shasum -a 256 | cut -d' ' -f1)

    curl -X POST https://app.cats.fund/api/v1/keys/claim \
      -H "Content-Type: application/json" \
      --cookie "cats_session=..." \
      -d "{"requestId":"$REQUEST_ID","keyHash":"$HASH"}"

What an order can express

Enough to run a strategy, not just to buy and sell. Every field below is recorded as a timestamped event and replayed by the same engine that judges a human evaluation — so a stop is part of the audit trail, not a note your bot keeps to itself.

Market
intent: "open" with a size. Fills at the recorded venue price for the moment it was submitted. There is no price field on an order — you cannot name your own fill, and the engine has no discretion to give you a better one.
Resting
Add triggerPrice and triggerWhen. Whether that makes it a limit or a stop follows from where the price sat when you submitted it, and that is recorded rather than inferred later — a replay must not have to guess what the market looked like.
Protection
takeProfit and stopLoss on the opening order, or alone with intent: "protect". Three states: a value sets it, null clears it, and omitting it leaves it alone — which is what lets you move a stop without restating a target.
Ladders
protection{trigger, price, size} to scale out in parts. A ladder replaces the two scalar levels outright rather than merging with them: an order carrying both is one instruction, not two.
Cancel
intent: "cancel" with cancels naming the resting order. The cancel is its own event, so the record shows an order placed and then withdrawn — which is what happened, and reads differently from the order never existing.

A protect order carries no size and never fills. It exists so that setting a stop is an ordered, timestamped event like everything else the engine replays — levels held anywhere else could not be reconstructed, and there would be no way to say whether a stop was in place before a given tick.

Sizes are decimals

"size": "0.01" means one hundredth of a unit — not engine units. Sending 1000000 for one BTC is read literally, and the order is refused or filled at a size nobody intended.

Idempotency

Every order needs a clientOrderId. It is required rather than offered, because an agent retrying an ambiguous timeout has no human to notice the duplicate.

Same id, same payload
Returns the original order. No second position opens.
Same id, different payload
409. The key names an order that already exists.

Errors

A 404 means the account does not exist or is not yours — deliberately the same answer, so the API cannot be walked to discover which account ids are real.
